220 - Fretting corrosion

Fretting corrosion test device

For cable bending resistance tests according to VW75174 (PG16) LV 214 (PG16)
Holders for 5 test specimens at the same time
Stroke 0.1 to 200 µm
Tensile force max. 100 N
Optional: constant continuity test
Operating temperature -20 °C to +80 °C
Drive via programmable controller

  • Details
  • Option

  • Micro driven test slide
  • Holders for 5 test specimens at the same time
  • Stroke 0 - 200 µm, programmable
  • Accuracy 4 nm
  • Tensile force max. 100 N
  • Optional:
    Constant checking for continuity each interruption in continuity is logged. display of the ACTUAL position vacuum and low-temperature version
  • The controller is connected to the device by a 5-m long cable with plug
  • Control unit with colour touch display for inputting the test parameters:
    • Speed 0.1 to 999 Hz in 0.1 Hz steps
    • Stroke length 0 - 200 µm
    • Possible waiting time between cycles
    • Number of test cycles
    • Program number
    • Order number
  • The system is designed for an environmental temperature of -20 °C to +80 °C
  • Only rustproof materials are used
  • Power-rating: 230 V AC 50 Hz 500 W

  • Custom and new designs of all kinds
  • System complete with climatic chamber
  • Communication with PLC of the climatic chamber
  • Temperature measurement and logging
  • Storage and output via
    • USB or TCP/IP to the PC:
    • START / STOP date and time
    • Test parameters
    • Test modes
  • Individual design of the input mask and sequence control

    This device was developed in co-operation with LABCO.
